Heng's 68631-C2 26 x 26 Escape Hatch classAcustoms

What brand of escape hatch do you currently have?
Class A Customs carries Heng's Brand Escape Hatches

 The current design of Heng's brand escape hatches will not match older style Heng's escape hatches.

 Heng's purchased the Jensen/Elixir brand name some years ago.

 The following part numbers and design of the escape hatches are the only Heng's style we carry.
Ventline no longer makes escape hatches, the sizes and hinge assembly are not the same as Heng's, Elixir or Jensen brand, you can not put a Heng's lid on a Ventline escape hatch.


How are Escape Hatches Measured?
The name of the Heng's escape hatches are shortened names to easily identify the escape hatch, it is not the cut-out measurement or the flange measurement.

You will need to verify your cut-out dimension to accurately find the escape hatch you are needing.



Class A Customs
1130 County Road 6 West
Elkhart, IN 46514
Phone: (574) 206-0101





13 x 20 Escape Hatch by Heng’s Part #  31121-C2 - This Escape Hatch has a Plastic Frame
Rough Cut-out Opening Dimensions (this is the hole you will need in your unit)  14 ¼”  X 21"
Exterior Mounting Flange Dimensions (sits on the top of your unit) 16 ¾”  X 23 ¾”

Lid Measurements 15 ½” x 22 ½”
Lid Only Part # 90007-C1


15 x 22 Escape Hatch by Heng’s Part # 58621-C2
Rough Cut-out Opening Dimensions (this is the hole you will need in your unit) 17 ⅜” X 24 ⅝”
Exterior Mounting Flange Dimensions (sits on the top of your unit) 19"  X 26 ½”

Lid Measurements 18” x 25”
Lid Only Part # 90008-C1




Rough Cut-out Opening Dimensions (this is the hole you will need in your unit)  19 ¼ "  X 26 ¼ "
Exterior Mounting Flange Dimensions (sits on the top of your unit) 21"  X 28"

Lid Measurements 19 ½” x 26 ⅜”
Lid Only Part # 90088-C1


Rough Cut-out Opening Dimensions (this is the hole you will need in your unit)  21 ¼ " x 21 ¼ "
Exterior Mounting Flange Dimensions (sits on the top of your unit) 23"  x 23"

Lid Measurements 21 ½” x 21 ½”
Lid Only Part # 90129-C1

26 x 26 Escape Hatch by Heng’s Part # 68631-C2
Rough Cut-out Opening Dimensions (this is the hole you will need in your unit)  25 1/2" x 25 1/2"
Exterior Mounting Flange Dimensions (sits on the top of your unit) 27 ½ "  x 27 ½ ”

Lid Measurements 26” x 26”
Lid Only Part # 90014-C1



 Heng's "Curl" Style Hinge







Class A Customs
1130 County Road 6 West
Elkhart, IN 46514
Phone: (574) 206-0101

on
Labels:

Heng’s 66621-C2 22 x 22 Escape Hatch classAcustoms

What brand of escape hatch do you currently have?
Class A Customs carries Heng's Brand Escape Hatches

 The current design of Heng's brand escape hatches will not match older style Heng's escape hatches.

 Heng's purchased the Jensen/Elixir brand name some years ago.

 The following part numbers and design of the escape hatches are the only Heng's style we carry.
Ventline no longer makes escape hatches, the sizes and hinge assembly are not the same as Heng's, Elixir or Jensen brand, you can not put a Heng's lid on a Ventline escape hatch.


How are Escape Hatches Measured?
The name of the Heng's escape hatches are shortened names to easily identify the escape hatch, it is not the cut-out measurement or the flange measurement.

You will need to verify your cut-out dimension to accurately find the escape hatch you are needing.



Class A Customs
1130 County Road 6 West
Elkhart, IN 46514
Phone: (574) 206-0101





13 x 20 Escape Hatch by Heng’s Part #  31121-C2 - This Escape Hatch has a Plastic Frame
Rough Cut-out Opening Dimensions (this is the hole you will need in your unit)  14 ¼”  X 21"
Exterior Mounting Flange Dimensions (sits on the top of your unit) 16 ¾”  X 23 ¾”

Lid Measurements 15 ½” x 22 ½”
Lid Only Part # 90007-C1


15 x 22 Escape Hatch by Heng’s Part # 58621-C2
Rough Cut-out Opening Dimensions (this is the hole you will need in your unit) 17 ⅜” X 24 ⅝”
Exterior Mounting Flange Dimensions (sits on the top of your unit) 19"  X 26 ½”

Lid Measurements 18” x 25”
Lid Only Part # 90008-C1




Rough Cut-out Opening Dimensions (this is the hole you will need in your unit)  19 ¼ "  X 26 ¼ "
Exterior Mounting Flange Dimensions (sits on the top of your unit) 21"  X 28"

Lid Measurements 19 ½” x 26 ⅜”
Lid Only Part # 90088-C1


Rough Cut-out Opening Dimensions (this is the hole you will need in your unit)  21 ¼ " x 21 ¼ "
Exterior Mounting Flange Dimensions (sits on the top of your unit) 23"  x 23"

Lid Measurements 21 ½” x 21 ½”
Lid Only Part # 90129-C1

26 x 26 Escape Hatch by Heng’s Part # 68631-C2
Rough Cut-out Opening Dimensions (this is the hole you will need in your unit)  25 1/2" x 25 1/2"
Exterior Mounting Flange Dimensions (sits on the top of your unit) 27 ½ "  x 27 ½ ”

Lid Measurements 26” x 26”
Lid Only Part # 90014-C1



 Heng's "Curl" Style Hinge







Class A Customs
1130 County Road 6 West
Elkhart, IN 46514
Phone: (574) 206-0101

on
Labels:

Heng's 90110-C1DL Thermal Pane Lid for 70000 Series Vortex Vents - White








Heng's Mini RV Roof Vent 17511-C1G and 18511-C1G









Aerodynamic Design Lid Color White
Screen Removable, strong, fine mesh screen
Handle Low Profile Plastic Manual Crank

Rough Cut-out Opening Dimensions (this is the hole you will need in your roof) 14.5” X 14.5”
Roof Flange Galvanized Steel with Mill Finish

Exterior Mounting Flange Dimensions (sits on the top of your unit) 16.5” X 16.5”
WARNING All Vent Metal Flanges are VERY SHARP use caution when touching

Available Inside Garnish Shroud Sizes 1" / 3" / 4" / 5" / 6" Vertical Leg (How far up into your ceiling it goes)

1.25” Wide Mounting Flange (trim you see inside on the roof)
Color White

No Mounting Hardware


Class A Customs
1130 County Road 6 West
Elkhart, IN 46514

Phone: (574) 206-0101








14" RV Roof Vent Garnish Rings
If you already have a garnish that you are comfortable re-using you do not need to purchase a unit with a garnish ring. Be sure to check the thickness of your roof to determine the correct size garnish ring to purchase with your roof vent.

Heng's Part # 90090
1” OEM Inside Garnish Shroud Color White 13" x 13" x 1 ⅛” Vertical Leg (How far up into your ceiling it goes) 1 ¼” Wide Mounting Flange (trim you see inside on the roof)

Heng's Part # 90092
3” OEM Inside Garnish Shroud Color White 13" x 13" x 3” Vertical Leg (How far up into your ceiling it goes) 1 ¼” Wide Mounting Flange (trim you see inside on the roof)

Heng's Part # 90094
4” OEM Inside Garnish Shroud Color White 13" x 13" x 4” Vertical Leg (How far up into your ceiling it goes) 1 ¼” Wide Mounting Flange (trim you see inside on the roof)

Heng's Part # 90144
5” OEM Inside Garnish Shroud Color White 13" x 13" x 5 ¼” Vertical Leg (How far up into your ceiling it goes) 1 ¼” Wide Mounting Flange (trim you see inside on the roof)

Heng's Part # 90146
6” OEM Inside Garnish Shroud Color White 13" x 13" x 6” Vertical Leg (How far up into your ceiling it goes) 1 ¼” Wide Mounting Flange (trim you see inside on the roof)







Heng's Brand Escape Hatches
The current design of Heng's brand escape hatches will not match older style Heng's escape hatches.



Heng's purchased the Jensen/Elixir brand name some years ago.



The following part numbers and design of the escape hatches are the only Heng's style we carry.


Ventline no longer makes escape hatches, the sizes and hinge assembly are not the same as Heng's, Elixir or Jensen brand, you can not put a Heng's lid on a Ventline escape hatch.



How are Escape Hatches Measured?
The name of the Heng's escape hatches are shortened names to easily identify the escape hatch, it is not the cut-out measurement or the flange measurement.

You will need to verify your cut-out dimension to accurately find the escape hatch you are needing.



Class A Customs
1130 County Road 6 West
Elkhart, IN 46514
Phone: (574) 206-0101





13 x 20 Escape Hatch by Heng’s Part #  31121-C2 - This Escape Hatch has a Plastic Frame
Rough Cut-out Opening Dimensions (this is the hole you will need in your unit)  14 ¼”  X 21"
Exterior Mounting Flange Dimensions (sits on the top of your unit) 16 ¾”  X 23 ¾”

Lid Measurements 15 ½” x 22 ½”
Lid Only Part # 90007-C1


15 x 22 Escape Hatch by Heng’s Part # 58621-C2
Rough Cut-out Opening Dimensions (this is the hole you will need in your unit) 17 ⅜” X 24 ⅝”
Exterior Mounting Flange Dimensions (sits on the top of your unit) 19"  X 26 ½”

Lid Measurements 18” x 25”
Lid Only Part # 90008-C1




Rough Cut-out Opening Dimensions (this is the hole you will need in your unit)  19 ¼ "  X 26 ¼ "
Exterior Mounting Flange Dimensions (sits on the top of your unit) 21"  X 28"

Lid Measurements 19 ½” x 26 ⅜”
Lid Only Part # 90088-C1


Rough Cut-out Opening Dimensions (this is the hole you will need in your unit)  21 ¼ " x 21 ¼ "
Exterior Mounting Flange Dimensions (sits on the top of your unit) 23"  x 23"

Lid Measurements 21 ½” x 21 ½”
Lid Only Part # 90129-C1

26 x 26 Escape Hatch by Heng’s Part # 68631-C2
Rough Cut-out Opening Dimensions (this is the hole you will need in your unit)  25 1/2" x 25 1/2"
Exterior Mounting Flange Dimensions (sits on the top of your unit) 27 ½ "  x 27 ½ ”

Lid Measurements 26” x 26”
Lid Only Part # 90014-C1



 Heng's "Curl" Style Hinge







Class A Customs
1130 County Road 6 West
Elkhart, IN 46514
Phone: (574) 206-0101
